Make Stellar/Star Data Maps In GIS

Read More

I have a latent interest in stargazing but haven’t done much about it for a long time until the past weekend when I had a bit of time and wondered if I could create a star map using QGIS. I found a couple tutorials and stackexchange questions that referenced David Nash’s HYG Database from Some of the tutorials showed equations for computing latitude and longitude from the star position values – ascension, declination specifically. However, I found that there is already an X and Y column in the latest version of the dataset which makes it easy to map, here’s how.

Download the Star Location Data

From the HYG Database page, grab the HYG version 3.0 dataset:

  • HYG 3.0: Database containing all stars in Hipparcos, Yale Bright Star, and Gliese catalogs (almost 120,000 stars, 14 MB)

The resulting 34MB CSV file contains about 20 columns and 119,615 rows.

Import CSV File into QGIS

  1. Launch QGIS (I’m using 2.10.1-Pisa)
  2. Select Layer -> Add Layer -> Add Delimited Text Layer
  3. Browse to the file location, select File Format radio button as CSV and the rest should take care of itself

Form importing the HYG Database star map CSV file into QGIS

Tweak the Map

If you use a typical WGS84 projection you’ll get a ton of points oriented in a circle.  I took a few minutes to zoom into a meaningful scale (for me it was around 1:5M), change the background colour and then use the LUM attribute to change the relative size of the stars.  I also changed the colours to be shades of white.  Here is what I was able to produce.  It’s not all that meaningful to me but I know that when I need to dig into the data further it will be available!


I’ve attached my project file here so you can get started quickly.

I’d love to hear what you would use this kind of data for and if you have any tips for making it more useful or better rendered.

Trick serving a hillshade image from GeoServer

Read More
When GeoServer skews the image it creates a region around the image that has value=0.  This image already had nodata=255, so it can be very confusing.
When GeoServer skews the image it creates a region around the image that has value=0. This image already had nodata=255, so it can be very confusing.

I had the perfect hillshade raster ready to throw on top of my web map, I had previewed it in QGIS and the colour stretching and values looked fine.
Hillshade in QGIS

I then loaded it into GeoServer and it looked great in the OpenLayers Layer Preview window as well.

However, once I added it as a WMS layer in a Leaflet map, I got really confused.  Even though I had my NODATA=255 parameters seemingly working well there appeared a small strip around the outside of the image that was obnoxious.

When GeoServer skews the image it creates a region around the image that has value=0.  This image already had nodata=255, so it can be very confusing.
When GeoServer skews the image it creates a region around the image that has value=0. This image already had nodata=255, so it can be very confusing.

I figured I could change it with an SLD but hadn’t done it before so it took a while to figure out.  For a couple hours I tried various permutations of the default “raster” Style, but with no luck.  The image, otherwise, looked great so the Style obviously wasn’t a real problem in and of itself.

The trick came when I realised that I need to set my color maps for the gray band explicitly.  Up to this point no particular band had been isolated for color mapping.  I found the right place to put the elements in the SLD and all worked out well.

My takeaway: there must be a better way to develop SLD for rasters.  The options in the GeoServer docs are amazing and exciting, but trying to fit them into a specific context has always been a challenge for me.  That’s why I had to write this down, but I’m sure I’ll have to remember it all again a year from now!

Note there is no skewed "collar" around the image as value=0 is ignored.
Note there is no skewed “collar” around the image as value=0 is ignored.




Day 1 – Building a 3D Game using Geo Data (Hobby project)

Read More
Day 1 - Unity 3D real time rendering of geodata

We are a team of three guys (so far) with a design idea for a simple yet challenging racing/strategy game based on real-world geospatial data coupled with a 3D gaming engine. Tonight we started building it together in Unity after downloading a bunch of public geospatial datasets. Here’s a summary of what we’ve done and some basic screenshots. The goal is to make progress every couple days to show we is possible with a little work and a combination of creative, technical and group management skillsets.

First Images

Day 1 - Unity 3D real time rendering of geodata

Starting with Geography

The landscape of our 3D game is built using real world geographic information – aka geospatial data. We wanted this so that we could build games around real locales and market the game to local users. One side benefit is the players will learn a little about Canadian geography!

We’ve got a great collection of geo data for all of Canada available through the government Geogratis website. After we’ve decided what map tile numbers we needed, we grab the CDED data which is a TIFF elevation image file with geographic coordinates included.

We also found a BC provincial shaded relief map layer that was pretty nice as a starter. As both these data files are geolocated we can load the data into GIS (geographic information system) software from and combine it with any other data we have for the region. In our case we have a “populated places” point file from that we show as stars on top of the shaded relief map.

Then we export the elevation data and the relief data (including the stars) into two files for Unity to ingest. The result is one PNG that is going to be our texture and the other will be the heightmap for the terrain.


Loading into Unity

We created a terrain object with some pretty huge dimensions and height. There are mountains in the region we are working with, so it’s pretty cool to see. We apply the heightmap using a commonly used Unity script (I’ll have to put the link here when I remember where I got it!).

Then we add the shade relief map as a texture to the terrain et voila! We threw in a plane of basic water and raised it to the level where it filled the main river valleys. As our game is going to first start as a river racing game, we want to start with water from the very beginning.

We added a car, parented it to the camera and were racing down our waterways within 2 hours of starting. We spent a lot of time adjusting sizes of terrains and texture so we could try to match real-world scale. There are some further ideas we are going to try to optimise this as well as nail down a workflow for easily ingesting new geodata for other regions (as we had to manually export and adjust things in the GIS).

Reposted from our Indiedb blog, hence writing for a slightly non-geo audience:


PDF Map Hack – Remove Embedded Image

Read More

Need to remove an embedded image from a PDF file?  You can easily chop out parts of it as needed with the PDFtk command line tool and a little bit of text editing.  Here’s how… Continue reading “PDF Map Hack – Remove Embedded Image”

Generate terrain with flowing water from DEM in Unity

Read More

Just a quick video follow up based on a reader asking how I did what I did in my previous post with Unity ( game engine.

Using Surface Wave asset and built-in Unity Terrain generator, plus a script for taking DEMs and creating Terrains easily.  I’m really new at this by the way, but have a brilliant teacher showing me this stuff in my spare time 🙂


High speed water flow simulation on a DEM

Read More

I’m helping some friends who are working on a project to visualise a whole whack of GIS data in Unity ( game engine.  It looks like we’ll end up working on a GIS -> Unity workflow for generating terrains from DEMs and texture maps from orthophotos.  To top it off they’ve already got a landcover classification app running that takes landcover raster classes and creates 3D objects (grass, trees, water) in the model.  (Don’t worry, I won’t tease you by mentioning their voxel based subsurface soil model interaction).  It’s still early but really encouraging so far.

Next up is to simulate water flow in the environment and it was slim pickings for options for doing this.  Then they found the Unity asset called Surface Waves (US$80) – it does the water flow work we wanted but much more.  I just posted a really short test video to see how it worked – with both an auto generated water source and a manual placement water source, like a paint brush, that allows you to see how things will flow. It is amazingly performant on a notebook.

Be sure to check out Surface Waves’ demo video – it frees you from trying to emulate the look of water movement through shader trickery to actually simulating water flow over and around objects.  Things that used to take a sophisticated GIS quite a while to compute actually, the last time I tried anyway 🙂

More to come as we play around with it, but I put it out there in case other spatially oriented folks might be interested as well in the GIS -> Unity workflow challenges being worked through.  If so, I’ll do more video highlighting the work that’s underway.

Web Mapping Illustrated – 10 year celebration giveaway [ENDED!]

Read More
My O'Reilly, 2005 book
My O’Reilly, 2005 book

Update: All copies are gone!  If you want Geospatial Desktop or Geospatial Power Tools – go to – quantity discounts available.  For Web Mapping Illustrated go to Amazon.


I’m giving away a couple copies of my circa 2005 classic book.  Details below…  When O’Reilly published Web Mapping Illustrated – Using Open Source GIS Toolkits – nothing like it existed on the market.  It was a gamble but worked out well in the end.

Primarily focused on MapServer, GDAL/OGR and PostGIS, it is a how-to guide for those building web apps that included maps.  That’s right, you couldn’t just use somebody else’s maps all the time – us geographers needed jobs, after all.

To help give you the context of the times, a couple months before the final print date, Google Maps, was released.  I blithely added a reference to their site just in case it became popular.

The book is still selling today and though I haven’t reviewed it in a while, I do believe many of the concepts are still as valid as when it was written.  In fact, it’s even easier to install and configure the apps now due to packaging and distribution options that didn’t exist back then.  Note this was also a year before’s collaborative efforts started to help popularise the tools further.

In celebration of 10 years of sales I have a couple autographed copies as giveaways to the first two people who don’t mind paying only for the shipping (about USD$8) and who drop me a note expressing their interest.

Additionally, I have some of Gary Sherman’s excellent Geospatial Desktop books as giveaways as well.  Same deal, pay actual shipping cost only from my remote hut in northern Canada.  Just let me know you’d like one of them and I’ll email you the PayPal details.  Sorry, not autographed by Gary, though I was editor and publisher, so could scribble on it for you if desired.

Geospatial Power Tools Reviews [Book]

Thinking of buying my latest book?  We’ve finally got a few reviews on Amazon that might help you decide.  See my other post for more about the book.  Buy the PDF on Locate

Reader Reviews

Geospatial Power Tools book cover

5.0 out of 5 stars This book makes a great reference manual for using GDAL/OGR suite of command line …,
January 24, 2015 By Leo Hsu
“The GDAL Toolkit is chuckful of ETL commandline tools for working with 100s of spatial (and not so spatial data sources). Sadly the GDAL website only provides the basic API command switches with very few examples to get a user going with. I was really excited when this book was announced and purchased as soon as it came out. This book makes a great reference manual for using GDAL/OGR suite of command line utilities.
Several chapters are devoted to each commandline tool, explaining what its for, the switches it has, and several examples of how to use each one. You’ll learn how to work with both vector/(basic data no vector) data sources and how to convert from one vector format to another. You’ll also learn how to work with raster data and how to transform from one raster data source to another as well as various operations you can perform on these.”


Continue reading “Geospatial Power Tools Reviews [Book]”

Converting Decimal Degree Coordinates

Read More
cs2cs command from GDAL/OGR toolset ( - allows robust coordinate transformations.
cs2cs command from GDAL/OGR toolset ( - allows robust coordinate transformations.

Converting Decimal Degree Coordinates to/from DMS Degrees Minutes Seconds

cs2cs command from GDAL/OGR toolset ( - allows robust coordinate transformations.
cs2cs command from GDAL/OGR toolset ( – allows robust coordinate transformations.

If you have files or apps that have to filter or convert coordinates – then the cs2cs command is for you.  It comes with most distributions of the GDAL/OGR ( toolset.  Here is one popular example for converting between degrees minutes and seconds (DMS) and decimal degrees (DD).

Geospatial Power Tools book coverThe following is an excerpt from the book: Geospatial Power Tools – Open Source GDAL/OGR Command Line Tools by me, Tyler Mitchell.  The book is a comprehensive manual as well as a guide to typical data processing workflows, such as the following short sample…

Input coordinates can come from the command line or an external file. Assuming a file containing DMS (degree, minute, seconds) style, looks like:

124d10'20"W 52d14'22"N
122d20'05"W 54d12'00"N

Use the cs2cs command, specifying how the print format will be returned, using the -f option. In this case -f “%.6f”
is explicitly requesting a decimal degree number with 6 decimals:

cs2cs -f "%.6f" +proj=latlong +datum=WGS84 input.txt

Example Converting DMS to/from DD

This will return the results, notice no 3D/Z value was provided, so none is returned:

-124.172222 52.239444 0.000000
-122.334722 54.200000 0.000000

To do the inverse, remove the formatting option and provide a list of values in decimal degree (DD):

cs2cs +proj=latlong +datum=WGS84 inputdms.txt
124d10'19.999"W 52d14'21.998"N 0.000
122d20'4.999"W 54d12'N 0.000

Geospatial Power Tools is 350+ pages long – 100 of those pages cover these kinds of workflow topic examples. Each copy includes a complete (edited!) set of the GDAL/OGR command line documentation as well as the following topics/examples:

Workflow Table of Contents

  1. Report Raster Information – gdalinfo
  2. Web Services – Retrieving Rasters (WMS)
  3. Report Vector Information – ogrinfo
  4. Web Services – Retrieving Vectors (WFS)
  5. Translate Rasters – gdal_translate
  6. Translate Vectors – ogr2ogr
  7. Transform Rasters – gdalwarp
  8. Create Raster Overviews – gdaladdo
  9. Create Tile Map Structure – gdal2tiles
  10. MapServer Raster Tileindex – gdaltindex
  11. MapServer Vector Tileindex – ogrtindex
  12. Virtual Raster Format – gdalbuildvrt
  13. Virtual Vector Format – ogr2vrt
  14. Raster Mosaics – gdal_merge

My new book on Amazon – raster/vector data manipulation using GDAL/OGR

Read More
Geospatial Power Tools by Tyler Mitchell now on Amazon
Geospatial Power Tools by Tyler Mitchell now on Amazon
Geospatial Power Tools by Tyler Mitchell now on Amazon
Geospatial Power Tools by Tyler Mitchell now on Amazon

Ten years ago I wrote a book for O’Reilly called Web Mapping Illustrated – using open source GIS tools. It was mostly about how to use MapServer and PostGIS to publish maps on the web and was the first of its kind in the marketplace.

This year I’ve completed my second book, for Locate Press, which focused on even more low level geospatial data manipulation using the GDAL/OGR command line tools. This was a work-in-progress for a couple of years, but has just now been released on Amazon as Geospatial Power Tools.

If you’re looking for a resource to understand how to convert imagery, vector data or to build elevation shaded maps or contours, and more, then this book is for you. It includes complete GDAL and OGR documentation. A third of the book presents new material geared to help you learn how to do specific kinds of processing tasks – from downloading from web services, to quickly converting imagery into an online map. A PDF version is also available and Kindle will likely come over the next 6 months.

I’m always interested in feedback on the book and to learn more about how to improve the next edition.
